Incoloy Alloy 800/800h/800ht Tubes, Alloy 825 Seamless Pipes Suppliers, Alloy 800ht Tubing Exporters in India

Alloy 800 Pipes Suppliers, Incoloy Tubing Suppliers, Incoloy 825 Tubes Suppliers, Alloy 800 Seamless Pipes Manufacturers in India

Seamless Alloy 800 Tubes, Alloy 825 Pipes Exporters in India, Uns N08800 / Uns N08825 Seamless Tubes, Tubing Suppliers, Worldwide Distributor Of Alloy 800HT/825 Tubing, Incoloy 800HT/825 Pipes! Exports Is Our Specialty!!!!!

NICKEL ALLOYS	TRADENAME	UNS NO.	WERKSTOFF NO.	DENSITY (8.8 G/CM3)
Alloy 800	Incoloy 800	N08800	1.4876	8.0
Alloy 800H	Incoloy 800H	N08810	1.4876	8.0
Alloy 800HT	Incoloy 800HT	N08811	1.4876	8.0
Alloy 825	Incoloy 825	N08825	2.4858	8.18

Ready Stock Available
Incoloy Alloy 800,800HT,825 Tubes	100 ton

Request For Our Latest Prices On Alloy 800HT/825, Incoloy 800HT/825 Seamless And Welded Pipes, Tubes And Tubing!!!

Our Alloy 800HT/825 tube products can be offered in seamless, welded or welded and cold drawn form, depending on the alloy you require. Our Alloy 800HT/825 seamless and welded tubes size range starts at 1/2” NB or OD size and goes up to 6″ NB and OD.

We can offer Nickel Alloy 800HT/825 Tubing in random lengths of up to 6meters long or cut to a specific length as ordered. Incoloy pipes and tubes are largely used for piping process systems.

Incoloy 800, Incoloy 800H and 800HT, are all nickel-iron-chromium alloys, with similar basic composition. However, Incoloy 800 differs from the other two alloys, due to the higher level of carbon in alloy 800H, and the addition of up to 1.20% aluminum and titanium in alloy 800HT. The high nickel and chromium contents of Incoloy 800H, 800HT and 800 ensure excellent resistance to oxidation. Incoloy 800 is primarily used in applications with temperatures up to 1100° F, where alloys 800H and 800HT are normally used in temperatures above 1100° F where resistance to creep and rupture is required.

Incoloy 825 is a nickel-iron-chromium alloy, with addition of molybdenum and copper, exhibiting excellent corrosion resistance in both reducing and oxidizing media. Alloy 825 offers good mechanical properties at both room and elevated temperatures, up to approximately 550℃.

Alloy 800HT/825 seamless pipes and tubing’s are available in both OD and NB sizes. In addition to standard sizes, which are available in stock, our specialty is to Supplier and supply custom size Alloy 800HT/825 cold drawn seamless tubing’s from our factory.









Specifications For Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825

	Seamless Pipe / Tubing	Welded Pipe / Tubing
Incoloy 800	ASTM B 407 / 163	ASTM B 514 / 515
	ASME SB 407 / 163	ASME SB 514 / 515
Incoloy 800H	ASTM B 407 / 163	ASTM B 514 / 515
	ASME SB 407 / 163	ASME SB 514 / 515
Incoloy 800HT	ASTM B 407 / 163	ASTM B 514 / 515
	ASME B 407 / 163	ASME SB 514 / 515
Incoloy 825	ASTM B 423 / 163	ASTM B 705 / 704
	ASME SB 423 / 163	ASME SB 705 / 704



Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825 Supply, Stock Range

We can offer ex-stock supply of most of the standard size Incoloy Alloy 800HT/825 pipes and Incoloy Alloy 800HT/825 tubes. Custom size (thickness x OD)  Alloy 800HT/825 pipes can be offered with short delivery times to meet the most demanding requirements of our customers.

Products	OD		WT		Length
	Inch	MM	Inch	MM	Ft max.	Mt max.
Alloy 800HT/825 Tube	1/2’’-3’’	12.0-76.2	0.02’’-0.5’’	0.5-12.0	105’	32.00
Alloy 800HT/825 Pipe	NPS1/2’’-6’’	21.34-168.3	Sch10-Sch80	2.11-12.7	98’	30.00



Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825 Chemical Composition %

Alloy 825	Ni	Fe	Cr	Mb	Cu	Ti	C	Mn	S	Si	Al
	38.0-46.0	22.0 min	19.5-23.5	2.5-3.5	1.5-3.0	.6-1.2	0.05 max	1.0 max	0.03 max	0.5 max	0.2 max
Alloy 800	Ni	Fe	Cr	Cu	Ti	Al	C	Mn	S	Si
	30.0-35.0	39.5 min	19.0-23.0	.75 max	.15-.60	.15-.60	.1 max	1.5 max	.015 max	1.0 max
Alloy 800H	Ni	Fe	Cr	Cu	Ti	Al	C	Mn	S	Si
	30.0-35.0	39.5 min	19.0-23.0	.75 max	.15-.60	.15-.60	.05-.10 max	1.5 max	.015 max	1.0 max
Alloy 800HT	Ni	Fe	Cr	Cu	Ti	Al	C	Mn	S	Si
	30.0-35.0	39.5 min	19.0-23.0	.75 max	.25-.60	.85-1.20	.06-.10 max	1.5 max	.015 max	1.0 max



Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825 Mechanical Properties

	INCOLOY 800	INCOLOY 800H	INCOLOY 800HT	INCOLOY 825
Density	7.94 g/cm3	7.94 g/cm3	7.94 g/cm3	8.1 g/cm³
Melting Range,℃	1350-1400 ℃	1350-1400 ℃	1350-1400 ℃	1370-1400
Elongation %	30-35	30-35	30-35	30
Tensile strength – Mpa	500	500	500	550
Yield strength – Mpa	205	200	200	220
Brinell hardness (HB)	–	–	–	≤200



Typical Applications Of Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825

Incoloy super alloys such as Incoloy 800, Incoloy 800H, Incoloy 800HT and Incoloy 825 are widely used by the industrial furnaces, chemical processing, pulp and paper, nuclear engineering, pressure vessels, heat exchangers and heaters in power plants.

Brands we Stock & Supply of Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825

Authorised Dealer & distributor of
United Seamless Limited -usl	Bao Steel- Bao	Yangzhou Lontrin Steel Tube -lontrin	Sumitomo Metals Smtm	Tenaris -tnrs
Valourec & Mannesman -v&m	Wuxi	Maharastra Seamless Limited -msl	Indian Seamless Metal Tubes Limited _ismt	Jindal Saw Ltd -jsl

We are approved vendor & Suppliers of Incoloy Alloy 800HT/825 Seamless  Pipes, Alloy 800HT/825 Tubing’s, UNS N08800, UNS N08825 in GASCO, KNPC, SAUDI ARAMCO, SABIC, ORPIC, NIORDC, PIDMCO etc.

Vendor & Suppliers of
GASCO	KNPC	SAUDI ARAMCO	SABIC	ORPIC	PIDMCO
