Is:1239 Steel Pipes, Is:1239 Mild Steel Tubes, Is:1239 Black Erw Steel Pipes Exporters In India

Is: 1239(Part-1) 2004 Black Steel Pipes, Is:1239 Steel Tubes, Equivalent To Bs – 1387 / 1985, Is: 3589-2001, Is: 10577

Is:1239 Erw Pipes, Is:1239 Round Pipes, 1/2″ To 6″ Is:1239 Pipes, 5.5mm Thk Is:1239 Pipes Suppliers In Mumbai

Ready Stock Available
IS 1239 Steel Pipes	100 ton
IS 1239 Steel Tubes	100 ton
IS 1239 Black ERW Steel Pipes	100 ton

Request For Our Latest Prices On High Quality IS:1239 ERW Steel Pipes! Exports Is Our Specialty!!

As one of the leading suppliers of IS:1239 steel pipes in Mumbai, Steel Pipes Online Industries (Steel Pipes & Tube Division) stocks an extensive range of electric resistance welded (ERW) IS:1239 steel pipes in a size range of 15mm. N.B. to 150mm N.B. in the Light, Medium and Heavy classes. Steel Pipes Online also offers steel pipes in compliance with IS: 3589-2001 and IS: 10577-1982.

All IS:1239 steel pipes and black tubes supplied by Steel Pipes Online are produced in accordance with ASTM /IS/BS specifications. At Steel Pipes Online, we strictly adhere the scheme of Testing and Inspecting laid down by the Bureau of Indian Standards (BIS).

Steel Pipes And Tubes Dimensions Confirming To IS: 1239 (Part – I) – 2004, Equivalent To BS – 1387 / 1985

Nominal Bore		Outside Diameter		Light (A-Class) Thickness Weight		Medium (B-Class) Thickness Weight		Heavy (C-Class) Thickness Weight
Inch	mm	Inch	mm	mm	kg/mtr	mm	kg/mtr	mm	kg/mtr
1/8″	3 mm	0.406	10.32	1.80	0.361	2.00		2.65	0.493
1/4″	6 mm	0.532	13.49	1.80	0.517	2.35	0.407	2.90	0.769
3/8″	10 mm	0.872	17.10	1.80	0.674	2.35	0.852	2.90	1.02
1/2″	15 mm	0.844	21.43	2.00	0.952	2.65	1.122	3.25	1.45
3/4″	20 mm	1.094	27.20	2.35	1.410	2.65	1.580	3.25	1.90
1″	25 mm	1.312	33.80	2.65	2.010	3.25	2.440	4.05	2.97
1.1/4″	32 mm	1.656	42.90	2.65	2.580	3.25	3.140	4.05	3.84
1.1/2″	40 mm	1.906	48.40	2.90	3.250	3.25	3.610	4.05	4.43
2″	50 mm	2.375	60.30	2.90	4.110	3.65	5.100	4.47	6.17
2.1/2″	65 mm	3.004	76.20	3.25	5.840	3.65	6.610	4.47	7.90
3″	80 mm	3.500	88.90	3.25	6.810	4.05	8.470	4.85	10.1
4″	100 mm	4.500	114.30	3.65	9.890	4.50	12.10	5.40	14.4
5″	125 mm	5.500	139.70	–	–	4.85	16.20	5.40	17.8
6″	150 mm	6.500	165.10	–	–	4.85	19.20	5.40	21.2



Big Diameter Steel Pipes, ERW Pipes Confirming To IS 3589, Grade FE330, Grade FE410

Wall Thickness	NominalBore 7″ NB 193.7 mm OD	NominalBore 8″ NB 219.1 mm OD	NominalBore 10″ NB 273 mm OD	NominalBore 12″ NB 323.7 mm OD	NominalBore 14″ NB 355.6 mm OD	NominalBore 16″ NB 406.4 mm OD	NominalBore 18″ NB 457mm OD	NominalBore 20″ NB 508 mm OD
mm	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr
4.85	22.59	25.62	32.07	38.13	–	–	–	–
5.20	24.17	27.43	34.34	40.85	–	–	–	–
5.60	26.00	29.28	36.93	43.93	48.11	–	–
6.00	27.88	31.53	39.50	47.02	51.49	61.00	69.00	–
6.35	29.34	33.28	41.73	49.67	54.43	62.35	70.50	78.50
7.01	32.77	36.76	46.43	55.45	61.82	69.04	–	–
7.94	–	41.00	50.95	61.85	67.98	77.94	87.80	–
8.18	–	42.56	53.42	65.12	–	–	–	–
9.53	–	51.50	60.24	73.75	81.21	93.13	105.00	117.00
12.70	–	–	–	–	107.28	123.30	139.00	155.00



Steel Pipes, Steel Tubes Tolerance As Per IS:1239

(a) Thickness
(1)	Butt welded Light tubes	+Not limited – 8 percent
	Medium and Heavy tubes	+ Not Limited                                                        – 10 percent
(2)	Seamless Tubes	+Not Limited – 12.5 percent

(b) Weight :
(1)	Single tube (light series)	+10 percent  – 8 percent
(2)	Single tube  (medium & heavy Series)	+10 percent

IS:1239 Steel Pipes And Tubes Product, Stock Range

Size: 15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD)

Dimension & Tolerance: Black Steel Pipes Dimensions – IS: 1239 (Pt I) – 2004, Equivalent to BS – 1387 / 1985

Specifications: IS – 1239 (Part -1) 2004, Equivalent to BS – 1387 / 1985

Surface Finish: Black

Features: High Strength, Corrosion Resistant, High Toughness and Deformability

Length: As per customer’s requirement (Maximum upto 7 meters)

Features: High Strength, Corrosion Resistant, High Toughness and Deformability

What are the Applications of IS:1239 Steel Pipes and IS:1239 Steel Tubes?

1. Industrial Water Lines, Plant Piping
2. Agriculture and Irrigation
3. Galvanized Steel Fencings
4. Road Barriers
5. Parking Barriers
6. Temporary Fencings
7. Steel Gates & Windows
8. Road Side Railings
9. Structural and fabrication work
10. Water Pipelines
11. Sewerage Systems
12. Oil Pipe Lines
13. Oil Refinery Piping, Crude Oil Piping

Brands we Stock & Supply of Is 1239 Steel Pipes, Tubes

Authorised Dealer & distributors of
United Seamless Limited -usl	Bao Steel- Bao	Yangzhou Lontrin Steel Tube -lontrin	Sumitomo Metals Smtm	Tenaris -tnrs
Valourec & Mannesman -v&m	Wuxi	Maharastra Seamless Limited -msl	Indian Seamless Metal Tubes Limited _ismt	Jindal Saw Ltd -jsl

We are approved vendor & Suppliers of Is 1239 Steel Pipes, Tubes in GASCO, KNPC, SAUDI ARAMCO, SABIC, ORPIC, NIORDC, PIDMCO etc.

Vendor & Suppliers of
GASCO	KNPC	SAUDI ARAMCO	SABIC	ORPIC	PIDMCO
